Showing 1–12 of 27 results
D435
Available on backorder
| Weight | 4,000000 kg |
|---|---|
| Dimensions | 22,000000 × 33,000000 × 23,000000 cm |
| Manufacturer |
Intel® RealSense™ |
| Model Nº |
D435 |
| Size |
90 mm × 25,8 mm × 25 mm |
| Field of View |
87° × 58° (FOV (H x V) is measured +/-3° of stated value) |
| Environment |
Indoors/Outdoors |
| Connectivity |
USB-C * 3.1 Gen 1 |
| Image Sensor |
Rolling Shutter |
| Depth Image Size |
1280×720 |
| RGB Image Size |
1920×1080 |
| RGB FOV |
69º x 42º |
| Frame Rate |
30 fps |
D435f
Available on backorder
| Weight | 4,000000 kg |
|---|---|
| Dimensions | 22,000000 × 33,000000 × 23,000000 cm |
| Manufacturer |
Intel® RealSense™ |
| Model Nº |
D435f |
| Size |
90 mm × 25,8 mm × 25 mm |
| Field of View |
87° × 58° (FOV (H x V) is measured +/-3° of stated value) |
| Environment |
Indoors/Outdoors |
| Connectivity |
USB-C * 3.1 Gen 1 |
| Image Sensor |
Rolling Shutter |
| Depth Image Size |
1280×720 |
| RGB Image Size |
1920×1080 |
| RGB FOV |
86° ±3° × 57° ±3° |
| Frame Rate |
30 fps |
A65 IR
Available on backorder
| Weight | 2,500000 kg |
|---|---|
| Dimensions | 17,000000 × 20,000000 × 10,000000 cm |
| Manufacturer |
FLIR |
| Model Nº |
IR A65 |
| Accuracy |
±5°C (±9°F) or ±5% of reading |
| Temperature |
–25 to +135°C (–13 to 275°F) |
| Field of View |
45° × 37° |
| Scan frecuency |
7,5 Hz |
| IR Resolution |
640 × 512 pixels |
| Thermal sensitivity / NETD |
Below 0,05°C @ +30°C (+86°F) / 50 mK |
| Spatial resolution (IFOV) |
1,31 mrad |
| F number |
1.25 |
| Focus |
Fixed |
| Detector Type |
Focal Plane Array (FPA), Uncooled VOX microbolometer |
| Spectral Range |
7,5–13 μm |
| Detector Pitch |
17 μm |
| Detector time constant |
Typical 12 ms |
| Ethernet |
Control and image |
| Ethernet Type |
Gigabit Ethernet |
| Ethernet, connector type |
RJ45 |
| Ethernet, communication |
GigE Vision ver. 1.2 Client API GenICam compliant |
| Ethernet, standard |
IEEE 802.3 |
| Focal Lenght |
Focal length 13 mm (0,5 in.) |
Airy
Available on backorder
| Weight | 1 kg |
|---|---|
| Dimensions | 34,000000 × 39,000000 × 39,000000 cm |
| Manufacturer |
Robosense |
| Model Nº |
Airy |
| Temperature |
-40°C ~ +60°C |
| Size |
Ø 60 mm |
| Weight |
230 ± 20 g |
| Voltage |
9 ~32 V |
| Range |
60m (30m @10% NIST) |
| Resolution angle |
Horizontal: 0.4º | Vertical: 0.947º |
| Enclosure class |
IP67, IP6K9K |
| Power Consumption |
8W (Typical) |
| Ethernet |
100 MBps |
| Field of view (horizontal) |
0~360° |
| Field of view (vertical) |
0~90° |
| Accuracy |
1.5 cm (1σ) |
RS-HELIOS-16P
Available on backorder
| Weight | 8,000000 kg |
|---|---|
| Dimensions | 34,000000 × 39,000000 × 39,000000 cm |
| Manufacturer |
Robosense |
| Model Nº |
RS-HELIOS-16P |
| Accuracy |
±2cm(typical) |
| Temperature |
-40°C ~ +60°C |
| Size |
φ97.5mm * H100mm |
| Weight |
1.000 g ± 50 g |
| Voltage |
9 ~32 V |
| Range |
150 m (110 m @10% NIST) |
| Enclosure class |
IP67 |
| Power Consumption |
11W |
| Laser beam |
16 beams |
| Laser class |
class 1 |
| Wavelength |
905 nm |
| Data rate |
~288.000 pts/s (single return) / 576.000 pts/s (dual return) |
| Field of view (horizontal) |
360º |
| Field of view (vertical) |
30° (-15° ~+15°) |
RS-Bpearl
Available on backorder
| Weight | 8,000000 kg |
|---|---|
| Dimensions | 34,000000 × 39,000000 × 39,000000 cm |
| Manufacturer |
Robosense |
| Model Nº |
RS-Bpearl |
| Temperature |
-30 ° C a + 60 ° C |
| Accuracy |
± 3cm |
| Size |
H: 100mm * φ: 111mm |
| Weight |
0,92 kg (without cabling) |
| Laser beam |
32 beams |
| Wavelength |
905 nm |
| Laser class |
class 1 |
| Data rate |
576.000 pts/s |
| Data type |
spatial coordinates/intensity |
| Field of view (horizontal) |
360º |
| Field of view (vertical) |
90º |
| Input voltage |
9-32VDC |
| RPM |
300 rpm a 1200 rpm (5Hz a 20Hz) |
RS-HELIOS 1610
Available on backorder
| Weight | 8,000000 kg |
|---|---|
| Dimensions | 34,000000 × 39,000000 × 39,000000 cm |
| Manufacturer |
Robosense |
| Model Nº |
RS-HELIOS 1610 |
| Accuracy |
±2cm (1m to 100m), ±3cm (0.1m to 1m), ±3cm (100m to 150m) |
| Temperature |
-30°C to 60°C |
| Data rate |
576.000 pts/s (single return) / 1.152.000 pts/s(dual return) |
| Field of view (horizontal) |
360º |
| Field of view (vertical) |
26° (-16° to +10°) |
| Front camera |
1º |
| Laser beam |
32 beams |
| Laser class |
class1 |
| RPM |
600 / 1200 rpm |
| Voltage |
9 ~32 V |
| Wavelength |
905nm |
| Weight |
~1 kg |
| Size |
φ: 100 mm * H100 mm |
| Enclosure class |
IP67 |
RS-HELIOS 5515
Available on backorder
| Weight | 8,000000 kg |
|---|---|
| Dimensions | 34,000000 × 39,000000 × 39,000000 cm |
| Manufacturer |
Robosense |
| Model Nº |
RS-HELIOS 5515 |
| Temperature |
-30°C to 60°C |
| Accuracy |
±2cm (1m to 100m), ±3cm (0.1m to 1m), ±3cm (100m to 150m) |
| Weight |
~1 kg |
| Voltage |
9 ~32 V |
| Enclosure class |
IP67 |
| Data rate |
576.000 pts/s (single return) / 1.152.000 pts/s(dual return) |
| Field of view (horizontal) |
360º |
| Field of view (vertical) |
70° (-55° to +15°) |
| Front camera |
Up to 1,33º |
| Laser beam |
32 beams |
| Laser class |
class1 |
| RPM |
600 / 1200 rpm |
| Wavelength |
905 nm |
| Size |
φ: 100 mm * H100 mm |
RS-Ruby Plus
Available on backorder
| Weight | 8,000000 kg |
|---|---|
| Dimensions | 34,000000 × 39,000000 × 39,000000 cm |
| Manufacturer |
Robosense |
| Model Nº |
RS-RUBY PLUS |
| Data rate |
2.304.000 pts/s (single return) |
| Data type |
Spatial Coordinates, Intensity, Timestamp |
| Field of view (horizontal) |
360º |
| Field of view (vertical) |
40 ° |
| Input voltage |
9-32V |
| Laser beam |
128 beams |
| Laser class |
class 1 |
| RPM |
600/1200 rpm (10Hz/20Hz) |
| Wavelength |
905 nm |
| Weight |
1,85 kg (without cabling) |
| Size |
φ: 125mm* H128mm |
E1R
Available on backorder
| Weight | 1 kg |
|---|---|
| Dimensions | 34,000000 × 39,000000 × 39,000000 cm |
| Manufacturer |
Robosense |
| Model Nº |
E1R LIDAR |
| Temperature |
-40º C – +85ºC |
| Size |
69,5 x 95x 43 mm |
| Weight |
330 g |
| Voltage |
9 ~16 V |
| Speed |
Dual return mode: [540.000 pts/s (10 Hz) | 1.080.000 pts/s (20 Hz) | 1.620.000 pts/s (30 Hz)] ,Single return mode: [270.000 pts/s (10 Hz) | 540.000 pts/s (20 Hz) | 810.000 pts/s (30 Hz)] |
| Range |
75m (30m@10%) |
| Resolution angle |
0,625º |
| Enclosure class |
IP67, IP6K9K |
| Wavelength |
940 nm |
FTN-Omega-191 SI-7200-1400
Available on backorder
| Weight | 50,000000 kg |
|---|---|
| Dimensions | 60,000000 × 60,000000 × 50,000000 cm |
| Manufacturer |
Schunk |
| Model Nº |
FTN-Omega-191 SI-7200-1400 |
| Weight |
9,41 kg |
| Height Z |
64 mm |
| Measuring range Fx, Fy |
± 7200 N |
| Measuring range Fz |
± 18000 N |
| Measuring range Mx, My |
± 1400 Nm |
| Measuring range Mz |
± 1400 Nm |
| Resolution Fx, Fy |
1,5 N |
| Resolution Fz |
3,0 N |
| Resolution Mx, My |
0,21 Nm |
| Resolution Mz |
0,14 Nm |
| Diameter |
190 mm |
| DAQ version |
Yes |
HEX Force Sensor
Available on backorder
| Weight | 1,500000 kg |
|---|---|
| Dimensions | 17,000000 × 12,000000 × 8,000000 cm |
| Manufacturer |
OnRobot |
| Model Nº |
HEX-H and HEX-E SENSOR |
| Size |
37,5 x 70 mm |
| Storage Temperature |
0 ºC – 55 °C |
| Weight |
245 g |
| Nominal Capacity (N.C.) |
HEX-E (Fxy: 200 N ; Fz: 200 N -Txy: 10 N·m ; Tz: 6.5 N·m) ,HEX-H (Fxy: 200 N ; Fz: 200 N ; Txy: 20 N·m ; Tz: 13 N·m) |
| Single axis deformation at N.C (typical) |
HEX-E (Fxy: ± 1,7 mm ; Fz: ± 0,3 mm ; Txy: ± 2,5 ° ; Tz: ± 5 °) ,HEX-H (Fxy: ± 0,6 mm ; Fz: ± 0,25 mm ; Txy: ± 2 ° ; Tz: ± 3,5 °) |
| Single axis overload |
HEX-E (Fxy: 500 % ; Fz: 500 % ; Txy: 500 % ; Tz: 500 %) ,HEX-H (Fxy: 500 % ; Fz: 400 % ; Txy: 300 % ; Tz: 300 %) |
| Signal noise2 (typical) |
HEX-E (Fxy: 0,035 N ; Fz: 0,15 N ; Txy: 0,002 N·m ; Tz: 0,001 N·m) ,HEX-H (Fxy: 0,1 N ; Fz: 0,2 N ; Txy: 0,006 N·m ; Tz: 0,002 N·m) |
| Noise-free resolution (typical) |
HEX-E (Fxy: 0,2 N ; Fz: 0,8 N ; Txy: 0,010 N·m ; Tz: 0,002 N·m) ,HEX-H (Fxy: 0,5 N ; Fz: 1 N ; Txy: 0,036 N·m ; Tz: 0,008 N·m) |
