Showing 1–12 of 94 results
RG2FT
Available on backorder
| Weight | 1,5 kg |
|---|---|
| Dimensions | 17 × 12 × 8 cm |
| Manufacturer |
OnRobot |
| Model Nº |
RG2-FT |
| Temperature |
5ºC – 50ºC |
| Weight |
0,77 kg |
| Current consumption |
6,5 W – 22 W |
| Full scale nonlinearity |
12 |
| Max. gripping force |
40 N |
| Max. stroke per jaw |
100 mm |
| Measuring area |
2 mm |
| Nominal Capacity (N.C.) |
Fxy: 20 N / Fz: 40 N / Txy: 0,7 Nm / Tz: 0,5 Nm |
| Noise-free resolution (typical) |
Fxy: 0,1 N / Fz: 0,4 N / Txy: 0,008 Nm / Tz: 0,005 Nm |
VGC10
Available on backorder
| Weight | 8 kg |
|---|---|
| Dimensions | 27 × 35 × 17 cm |
| Manufacturer |
OnRobot |
| Model Nº |
VGC10 |
| Size |
101 x 100 x 100 mm |
| Weight |
0,814 kg |
| Payload |
15 kg |
| Enclosure class |
IP54 |
| Operating Temperature |
0 °C – 50 °C |
| Vacuum |
5 % – 80 % Vacuum -0.05 – -0.810 Bar 1.5 – 24 inHg |
| Power supply |
Min 20.4 V / Typical 24 V / Max 28.8 V |
| Current consumption |
Min. 50 mA / Typical 600 mA / Max. 1500 mA |
| Vacuum cups |
1 – 7 pcs. |
| Gripping time |
0,35 s |
| Releasing time |
0,20 s |
| Vacuum pump |
Integrated, electric BLDC |
| Tool changer |
Integrated, click-on |
VG10
Available on backorder
| Weight | 2,5 kg |
|---|---|
| Dimensions | 17 × 22 × 12 cm |
| Manufacturer |
OnRobot |
| Model Nº |
VG10 |
| Payload |
10 kg |
| Reach |
32 mm – 358 mm |
| Operating Temperature |
0 °C – 50 °C |
| Vacuum |
5 % – 80 % Vacuum -0.05 – -0.810 Bar 1.5 – 24 inHg |
| Air flow |
12 Nl/min |
| Power supply |
Min 20.4 V / Typical 24 V / Max 28.8 V |
| Current consumption |
Min. 50 mA / Typical 600 mA / Max. 1500 mA |
| Adjustable arms |
270 |
| Holding torque arms |
6 Nm |
| Vacuum cups |
1 – 16 pcs. |
| Gripping time |
0,35 s |
| Releasing time |
0,20 s |
| Vacuum pump |
Integrated, electric BLDC |
| Arms |
4, adjustable by hand |
| Tool changer |
Integrated, click-on |
| Mechanical interface |
ISO 9409-1, 50-4-M6 |
| Pneumatic interface |
16x G1/8 internal threads |
| Electrical interface |
8-pole M8 |
2FGP20
Available on backorder
| Weight | 8,5 kg |
|---|---|
| Dimensions | 29 × 38 × 20 cm |
| Manufacturer |
OnRobot |
| Size |
400 x 121.6 x 188 mm |
| Weight |
3,7 kg |
| Payload |
20 kg |
| Enclosure class |
IP54 |
| Temperature |
0ºC – 60ºC |
| Drives |
Integrated, electric BLDC |
| Vacuum |
5 % – 80 % Vacuum -0.05 – -0.810 Bar 1.5 – 24 inHg |
| Power supply |
Min 20.4 V / Typical 24 V / Max 28.8 V |
| Gripping time |
0,25 s |
| Releasing time |
0,4 s |
D435
Available on backorder
| Weight | 4,000000 kg |
|---|---|
| Dimensions | 22,000000 × 33,000000 × 23,000000 cm |
| Manufacturer |
Intel® RealSense™ |
| Model Nº |
D435 |
| Size |
90 mm × 25,8 mm × 25 mm |
| Field of View |
87° × 58° (FOV (H x V) is measured +/-3° of stated value) |
| Environment |
Indoors/Outdoors |
| Connectivity |
USB-C * 3.1 Gen 1 |
| Image Sensor |
Rolling Shutter |
| Depth Image Size |
1280×720 |
| RGB Image Size |
1920×1080 |
| RGB FOV |
69º x 42º |
| Frame Rate |
30 fps |
D435f
Available on backorder
| Weight | 4,000000 kg |
|---|---|
| Dimensions | 22,000000 × 33,000000 × 23,000000 cm |
| Manufacturer |
Intel® RealSense™ |
| Model Nº |
D435f |
| Size |
90 mm × 25,8 mm × 25 mm |
| Field of View |
87° × 58° (FOV (H x V) is measured +/-3° of stated value) |
| Environment |
Indoors/Outdoors |
| Connectivity |
USB-C * 3.1 Gen 1 |
| Image Sensor |
Rolling Shutter |
| Depth Image Size |
1280×720 |
| RGB Image Size |
1920×1080 |
| RGB FOV |
86° ±3° × 57° ±3° |
| Frame Rate |
30 fps |
A65 IR
Available on backorder
| Weight | 2,500000 kg |
|---|---|
| Dimensions | 17,000000 × 20,000000 × 10,000000 cm |
| Manufacturer |
FLIR |
| Model Nº |
IR A65 |
| Accuracy |
±5°C (±9°F) or ±5% of reading |
| Temperature |
–25 to +135°C (–13 to 275°F) |
| Field of View |
45° × 37° |
| Scan frecuency |
7,5 Hz |
| IR Resolution |
640 × 512 pixels |
| Thermal sensitivity / NETD |
Below 0,05°C @ +30°C (+86°F) / 50 mK |
| Spatial resolution (IFOV) |
1,31 mrad |
| F number |
1.25 |
| Focus |
Fixed |
| Detector Type |
Focal Plane Array (FPA), Uncooled VOX microbolometer |
| Spectral Range |
7,5–13 μm |
| Detector Pitch |
17 μm |
| Detector time constant |
Typical 12 ms |
| Ethernet |
Control and image |
| Ethernet Type |
Gigabit Ethernet |
| Ethernet, connector type |
RJ45 |
| Ethernet, communication |
GigE Vision ver. 1.2 Client API GenICam compliant |
| Ethernet, standard |
IEEE 802.3 |
| Focal Lenght |
Focal length 13 mm (0,5 in.) |
Airy
Available on backorder
| Weight | 1 kg |
|---|---|
| Dimensions | 34,000000 × 39,000000 × 39,000000 cm |
| Manufacturer |
Robosense |
| Model Nº |
Airy |
| Temperature |
-40°C ~ +60°C |
| Size |
Ø 60 mm |
| Weight |
230 ± 20 g |
| Voltage |
9 ~32 V |
| Range |
60m (30m @10% NIST) |
| Resolution angle |
Horizontal: 0.4º | Vertical: 0.947º |
| Enclosure class |
IP67, IP6K9K |
| Power Consumption |
8W (Typical) |
| Ethernet |
100 MBps |
| Field of view (horizontal) |
0~360° |
| Field of view (vertical) |
0~90° |
| Accuracy |
1.5 cm (1σ) |
RS-HELIOS-16P
Available on backorder
| Weight | 8,000000 kg |
|---|---|
| Dimensions | 34,000000 × 39,000000 × 39,000000 cm |
| Manufacturer |
Robosense |
| Model Nº |
RS-HELIOS-16P |
| Accuracy |
±2cm(typical) |
| Temperature |
-40°C ~ +60°C |
| Size |
φ97.5mm * H100mm |
| Weight |
1.000 g ± 50 g |
| Voltage |
9 ~32 V |
| Range |
150 m (110 m @10% NIST) |
| Enclosure class |
IP67 |
| Power Consumption |
11W |
| Laser beam |
16 beams |
| Laser class |
class 1 |
| Wavelength |
905 nm |
| Data rate |
~288.000 pts/s (single return) / 576.000 pts/s (dual return) |
| Field of view (horizontal) |
360º |
| Field of view (vertical) |
30° (-15° ~+15°) |
