RB-KAIROS
Manufacturer: Robotnik Automation
Autonomous Mobile Robot.
Available on backorder
Available on backorder
RB-KAIROS is an AMR designed to automate indoor logistic tasks such as the transport of goods. It has a payload capacity of 250 kg and a robust steel design.
It incorporates omnidirectional kinematics that allow the robot to move in any direction, navigating faster and avoiding obstacles safely.
RB-KAIROS also offers the option of Plug & Play integration of a Universal Robots robotic arm, becoming the RB-KAIROS+ mobile manipulator and expanding its applications.
It is a modular robot with open architecture based on ROS 2.
Main features
-
- Omnidirectional kinematics.
- Modular.
- Collaborative.
- Compact and robust design.
Applications
-
- Logistics.
- Metrology.
- Parts feeding.
Components included
-
- CPU i7
- Battery UN38.3 – 48V@58Ah
- 5G Router
- IMU
- RGBD camera
- Safety Pack 360º
- 2D Safety LiDARs + Safety PLC
- Mecanum omnidirectional wheels
- Payload: 100 kg
- Charging station
| Model Nº | RB-KAIROS |
| Manufacturer | Robotnik Automation |
| Size | 978 x 776 x 690 mm |
| Weight | 115 kg |
| Speed | 1,5 m/s |
| Payload | Up to 250 kg |
| Environment | Indoors |
| Enclosure class | IP52 |
| Autonomy | Up to 12 h. |
| Traction motors | 4 x 500 W with brake |
| Kinematic | Omnidirectional |
| Localization system | SLAM |
| Temperature | 0ºC to 45ºC |
| Maximum slope | 15% |
| Communication | Bluetooth 4.0, WiFi 802.11 b/g/n/ac |
| Connectivity | 12 V, 24 V, VBATT, Ethernet, HDMI, USB |
Official ROS Packages:
- Source:
- Supported versions:
- Noetic.
