Showing 25–36 of 54 results
EGS 25-N-N-B
Available on backorder
| Weight | 0,000000 kg |
|---|---|
| Dimensions | 0,000000 × 0,000000 × 0,000000 cm |
| Manufacturer |
Schunk |
| Model Nº |
EGS 25-N-N-B |
| Ambient illuminance |
5º C – 55ªC |
| Weight |
0,45 kg |
| Voltage |
24 V |
| Current |
Max: 1,2 A – Nominal: 0,8 A |
| Length X |
69,8 mm |
| Width Y |
45 mm |
| Height Z |
88,8 mm |
| Stroke per jaw |
3 mm |
| Min. gripping force |
15 N |
| Max. gripping force |
30 N |
| Recommended workpiece weight |
0,15 kg |
| Max. permissible finger length |
32 mm |
| Max. permissible mass per finger |
0,02 kg |
| Opening time |
0,05 s |
| Closing time |
0,05 s |
EGU 50-PN-N-B
Available on backorder
| Weight | 0,000000 kg |
|---|---|
| Dimensions | 0,000000 × 0,000000 × 0,000000 cm |
| Manufacturer |
Schunk |
| Model Nº |
EGU 50-PN-N-B |
| Temperature |
5°C – 55°C |
| Weight |
1,44 kg |
| Length X |
122 mm |
| Height Z |
88 mm |
| Width Y |
72 mm |
| Enclosure class |
Electronics: IP67 Guide/base jaws: IP40 |
| Repeatability |
Repeat accuracy (gripping): 0.02 mm Repeat accuracy (positioning, unidirectional): 0.05 mm Repeat accuracy (positioning, bi-directional): 0.15 mm |
| Interface |
PROFINET |
| Stroke per jaw |
51 mm |
| Min. gripping force |
150 N |
| Max. gripping force |
300 N |
| Max. permissible finger length |
80 mm |
| Recommended workpiece weight |
0,4 kg |
| Opening time |
0,8 s |
| Closing time |
0.8 s |
Electric Screwdriver
Available on backorder
| Weight | 0,000000 kg |
|---|---|
| Dimensions | 0,000000 × 0,000000 × 0,000000 cm |
| Manufacturer |
OnRobot |
| Model Nº |
V 1.5 |
| Size |
308 x 86 x 114 mm |
| Accuracy |
0,04 – 3 Nm |
| Temperature |
5º C – 50º C / 95% |
| Operating Temperature |
0 °C – 50 °C |
| Power supply |
Min 20 V / Typical 24 V / Max 25 V |
| Storage Temperature |
0 °C – 60 °C |
| Torque |
0,15 – 5 Nm |
| Weight |
2,5 kg |
| Current consumption |
Min: 75 mA – Max: 4500 mA |
| Enclosure class |
IP54 |
EMH-RP 036-B
Available on backorder
| Weight | 0,000000 kg |
|---|---|
| Dimensions | 0,000000 × 0,000000 × 0,000000 cm |
| Manufacturer |
Schunk |
| Model Nº |
EMH-RP 036-B |
| Temperature |
5°C – 50°C |
| Enclosure class |
IP52 |
| Weight |
1 kg |
| Length X |
64 mm |
| Height Z |
128 mm |
| Width Y |
64 mm |
| Magnetic surfaces |
6,08 cm² |
| Response Time |
300 ms |
| Strength |
530 N |
| Voltage |
24 V |
| Current |
Max: 3,1 A / Nominal: 0,15 A |
Gecko SP
Available on backorder
| Weight | 1,5 kg |
|---|---|
| Dimensions | 17 × 12 × 8 cm |
| Manufacturer |
OnRobot |
| Model Nº |
Gecko Single Pad (SP) |
| Size |
69 x 71 mm |
| Payload |
1 kg / 3 kg / 5 kg |
| Weight |
0,267 kg / 0,297 kg / 0,318 kg |
| Enclosure class |
IP42 |
| Operating Temperature |
0 °C – 50 °C |
| Storage Temperature |
-30 °C – 150 °C |
| Gripper - Detachment time |
100-1000 |
| Pads - Change-out interval |
~200,000 cycles |
| Pads - Robotic cleaning interval and % recovery |
Variable / 100% |
| Pads - Material |
Proprietary silicone blend |
ROSbot 3
Available on backorder
| Weight | 15 kg |
|---|---|
| Dimensions | 45 × 38 × 44 cm |
| Model Nº |
ROSbot 3 |
| Manufacturer |
HUSARION |
| Size |
With camera and LiDAR: 200 x 233 x 197 mm ,Without camera and LiDAR: 200 x 233 x 103 mm ,Without camera: 200 x 233 x 141 mm |
| Weight |
With camera and LiDAR: 2,84 kg ,Without camera and LiDAR: 2,45 kg |
| Speed |
1 m/s |
| Payload |
Up to 5 kg (not in continuous work) |
| Battery |
1,5 – 5 h. |
ROSbot XL
Available on backorder
| Weight | 13 kg |
|---|---|
| Dimensions | 45 × 38 × 24 cm |
| Model Nº |
ROSbot XL |
| Manufacturer |
HUSARION |
| Size |
332 x 284 x 131 mm |
| Speed |
0.8 m/s |
| Microphones |
1 |
| Load capacity |
10 kg |
| Controller |
ROS |
| Traction system |
4 x DC motors + quadrature encoders |
| Autonomy |
2-6 H |
| Battery |
11.1V 7800mAh 86Wh |
| Environment |
Indoors |
| Connectivity |
Antenna connector, USB, HDMI, ETHERNET |
| Materials |
Powder-coated aluminum plate, 1.5 mm thick, top plate 3 mm |
RB-SUMMIT
Available on backorder
| Weight | 110 kg |
|---|---|
| Dimensions | 85 × 90 × 100 cm |
| Model Nº |
RB-SUMMIT |
| Size |
731 x 614 x 726 mm |
| Weight |
65 Kg |
| Speed |
2,5 m/s |
| Autonomy |
Up to 5 h |
| Payload |
Up to 50 kg |
| Environment |
Indoors/Outdoors |
| Enclosure class |
IP54 |
| Traction motors |
4 x 500 W with brake |
| Localization system | |
| Temperature |
-10ºC – 45ºC |
| Maximum slope |
80% |
| Communication |
Bluetooth 4.0 ,WiFi 802.11 b/g/n/ac |
| Connectivity |
5 V, 12 V, VBATT ,Ethernet ,USB |
RB-WATCHER
Available on backorder
| Weight | 110 kg |
|---|---|
| Dimensions | 85 × 90 × 100 cm |
| Model Nº |
RB-WATCHER |
| Manufacturer |
Robotnik Automation |
| Size |
736 x 614 x 894 mm |
| Weight |
73 kg |
| Speed |
2,5 m/s |
| Autonomy |
Up to 5 h |
| Payload |
Up to 50 kg |
| Enclosure class |
IP54 |
| Environment |
Indoors/Outdoors |
| Traction motors |
4 x 500 W with brake |
| Kinematic |
Skid steering |
| Localization system | |
| Temperature |
-10ºC – 45ºC |
| Maximum slope |
65% |
| Communication |
Bluetooth 4.0 ,WiFi 802.11 b/g/n/ac |
| Connectivity |
12 V, 24 V, VBATT ,Ethernet ,USB |
