Showing 25–36 of 67 results
Gen3 lite
Available on backorder
| Weight | 25,000000 kg |
|---|---|
| Dimensions | 45,000000 × 55,000000 × 45,000000 cm |
| Manufacturer |
Kinova Robotics |
| Model Nº |
Gen3 Lite |
| Interface |
USB-A, micro USB, Ethernet, Wi-Fi |
| Communication Protocol |
1 x 100 Mbps Ethernet |
| Temperature |
0°C to +40°C |
| Weight |
5,4 kg |
| Voltage |
18 to 30 VDC, 24 VDC nominal |
| Enclosure class |
IP22 |
| Payload |
600 g (mid-range) | 500 g (full-range) |
| Materials |
Carbon fiber Aluminium |
| Reach |
Maximum reach 760 mm |
Gen3
Available on backorder
| Weight | 30,000000 kg |
|---|---|
| Dimensions | 55,000000 × 65,000000 × 45,000000 cm |
| Manufacturer |
Kinova Robotics |
| Model Nº |
Gen3 7 DoF |
| Interface |
RS-4853, Ethernet: Ethernet, Ethernet, I2C 3, UART3, Power: 24 V |
| Communication Protocol |
2 x Fast Ethernet (100 Mbps) |
| Temperature |
-30 °C to 35 °C |
| Enclosure class |
IP33 |
| Weight |
8,2 kg (no gripper) |
| Payload |
4 kg (mid-range continuous; no gripper) / 4,5 kg (full-reach peak/temporary; no gripper) / 1,1 kg (full-reach continuous; no gripper) |
| DOF |
7 |
| Connectivity |
USB Gamepad Ethernet (Web App + API) 1 Gbps HDMI 1.4a3 Wi-Fi (Web App + API) IEEE 802.11a/b/g/n Bluetooth 4.0 + LE3 Digital I/O3 |
| Materials |
Carbon fiber Aluminium |
Gen2
Available on backorder
| Weight | 25 kg |
|---|---|
| Dimensions | 45 × 65 × 35 cm |
| Manufacturer |
Kinova Robotics |
| Model Nº |
Gen2 6 DoF |
| Interface |
RS-485 |
| Weight |
4,4 kg |
| Voltage |
18 – 29 VDC |
| Payload |
2.6 Kg (mid-range continuous payload capabilities) / 2.2 Kg (full-reach peak/temporary payload capabilities) |
| Materials |
Carbon fiber (links), aluminum (actuators) |
| Joint range after start-up (Software limitation) |
+- 27,7 turns |
| Maximun linear arm speed |
20 cm/s |
| Average power |
25 W (5W in Standby) |
| Water resistance |
IPX2 |
Link6
Available on backorder
| Weight | 0,000000 kg |
|---|---|
| Dimensions | 0,000000 × 0,000000 × 0,000000 cm |
| Manufacturer |
Kinova Robotics |
| Model Nº |
Kinova Link 6 |
| Processor |
Intel® CoreTM i7 |
| Temperature |
0°C to +40°C |
| Weight |
23,45 kg |
| Voltage |
110-240 VAC, 50-60 Hz |
| Speed |
2 m/s |
| Enclosure class |
IP54 |
| Payload |
6 kg (full-range, at 200 mm from wrist) |
| Materials |
Aluminum, ABS plastic |
| Reach |
1000 mm |
D1-T
Available on backorder
| Weight | 25,000000 kg |
|---|---|
| Dimensions | 45,000000 × 55,000000 × 45,000000 cm |
| Manufacturer |
Unitree |
| Model Nº |
D1-T |
| Interface |
DC5.5-2.1(Power Supply) RJ45（Communication） Type-C（Serial Port Debugging） |
| Weight |
2,37 kg |
| Voltage |
24V 2,5A (MAX 5A) |
| Strength |
60 W |
| Payload |
500 g |
| DOF |
6 Axis + 1 Gripper |
| Reach |
550 mm (Gripper not included) 670 mm (Gripper included) |
| Drives |
Bus servo |
EGK 25-IL-M-B
Available on backorder
| Weight | 0,000000 kg |
|---|---|
| Dimensions | 0,000000 × 0,000000 × 0,000000 cm |
| Manufacturer |
Schunk |
| Model Nº |
EGK 25-IL-M-B |
| Height Z |
78 mm |
| Length X |
83 mm |
| Width Y |
62 mm |
| Weight |
0,62 kg |
| Temperature |
5°C – 55°C |
| Max. gripping force |
50 N |
| Min. gripping force |
20 N |
| Stroke per jaw |
26,5 mm |
| Voltage |
24 V |
| Enclosure class |
Electronic system: IP67 Guides/Jaws: IP20 |
| Max. permissible finger length |
70 mm |
| Max. permissible mass per finger |
0,13 kg |
| Closing time |
0,37 s |
| Opening time |
0,37 s |
EGP
Available on backorder
| Weight | 1,500000 kg |
|---|---|
| Dimensions | 17,000000 × 12,000000 × 8,000000 cm |
| Manufacturer |
Schunk |
| Model Nº |
EGP |
| Weight |
Consult according to specific model |
| Temperature |
5°C – 55°C |
| Enclosure class |
IP30 |
| Current |
0,14 A |
| Voltage |
24 V |
| Max. stroke per jaw |
3 – 10 mm (depending on the model) |
| Min. gripping force |
40 – 150 N (depending on the model) |
| Max. gripping force |
40 – 150 N (depending on the model) |
| Recommended workpiece weight |
Up to 1,3 kg (depending on the model) |
| Max. permissible finger length |
Up to 50 mm or more (depending on the model) |
| Max. permissible mass per finger |
Consult according to specific model |
| Closing time |
0,2 s |
| Opening time |
0,2 s |
| Repeatability |
0,02 mm |
| Integrated sensors |
Position sensors |
| Size |
Consult according to specific model |
EGS 25-N-N-B
Available on backorder
| Weight | 0,000000 kg |
|---|---|
| Dimensions | 0,000000 × 0,000000 × 0,000000 cm |
| Manufacturer |
Schunk |
| Model Nº |
EGS 25-N-N-B |
| Ambient illuminance |
5º C – 55ªC |
| Weight |
0,45 kg |
| Voltage |
24 V |
| Current |
Max: 1,2 A – Nominal: 0,8 A |
| Length X |
69,8 mm |
| Width Y |
45 mm |
| Height Z |
88,8 mm |
| Stroke per jaw |
3 mm |
| Min. gripping force |
15 N |
| Max. gripping force |
30 N |
| Recommended workpiece weight |
0,15 kg |
| Max. permissible finger length |
32 mm |
| Max. permissible mass per finger |
0,02 kg |
| Opening time |
0,05 s |
| Closing time |
0,05 s |
EGU 50-PN-N-B
Available on backorder
| Weight | 0,000000 kg |
|---|---|
| Dimensions | 0,000000 × 0,000000 × 0,000000 cm |
| Manufacturer |
Schunk |
| Model Nº |
EGU 50-PN-N-B |
| Temperature |
5°C – 55°C |
| Weight |
1,44 kg |
| Length X |
122 mm |
| Height Z |
88 mm |
| Width Y |
72 mm |
| Enclosure class |
Electronics: IP67 Guide/base jaws: IP40 |
| Repeatability |
Repeat accuracy (gripping): 0.02 mm Repeat accuracy (positioning, unidirectional): 0.05 mm Repeat accuracy (positioning, bi-directional): 0.15 mm |
| Interface |
PROFINET |
| Stroke per jaw |
51 mm |
| Min. gripping force |
150 N |
| Max. gripping force |
300 N |
| Max. permissible finger length |
80 mm |
| Recommended workpiece weight |
0,4 kg |
| Opening time |
0,8 s |
| Closing time |
0.8 s |
Electric Screwdriver
Available on backorder
| Weight | 0,000000 kg |
|---|---|
| Dimensions | 0,000000 × 0,000000 × 0,000000 cm |
| Manufacturer |
OnRobot |
| Model Nº |
V 1.5 |
| Size |
308 x 86 x 114 mm |
| Accuracy |
0,04 – 3 Nm |
| Temperature |
5º C – 50º C / 95% |
| Operating Temperature |
0 °C – 50 °C |
| Power supply |
Min 20 V / Typical 24 V / Max 25 V |
| Storage Temperature |
0 °C – 60 °C |
| Torque |
0,15 – 5 Nm |
| Weight |
2,5 kg |
| Current consumption |
Min: 75 mA – Max: 4500 mA |
| Enclosure class |
IP54 |
